Key Features

• 9.4kWh high-capacity storage
• Long-lasting LiFePO₄ chemistry with over 6,000 cycles
• Advanced BMS with RS485/CAN communication
• Compatible with major inverter brands
• Safe, stable, and deep-cycle ready
• Parallel connection supported for larger systems
• Rack or wall mount design
• 10-year warranty with local support

Technical Specifications

• Nominal Energy – 9.4kWh
• Nominal Voltage – 51.2V
• Operating Voltage Range – 43.2–57.6V
• Cell Type – Blade LFP
• Dimension (WDH) – 430150800mm
• Weight – 72Kg
• Charging Temperature – From 0 to 50°C
• Discharging Temperature – From -20 to 60°C
• Depth of Discharge – 95% DOD
• Nominal Charge Current – 100A
• Nominal Discharge Current – 100A
• Maximum Parallel Number – 16
• Ingress Protection Degree – IP65
• Cooling Type – Natural convection
• Humidity – ≤95%
• Warranty – 10 years
• Communication – CAN/RS485/WIFI/Bluetooth
• Battery Safety – IEC 62619 / IEC 63056 / CE / RED
• Transportation Certification – UN38.3
