Key Features

• 6kW rated power with 12kVA surge

• Pure sine wave output for stable AC power

• Dual MPPT with 99.9% tracking efficiency

• Compatible with lithium-ion and lead-acid batteries

• 100A max PV and utility charging current

• Parallel operation: up to 6 units

• IP65 rated for outdoor or indoor use

• Time-slot function for peak-valley electricity savings

• Smart BMS communication via RS485/CAN

• Supports WiFi/GPRS monitoring

Off-grid Output

• Rated Output Power – 6000W

• Max. Peak Power – 12000VA

• Rated Output Voltage – 230Vac

• Load Capacity of Motors – 4HP

• Output Frequency Range – 50Hz ± 0.3Hz / 60Hz ± 0.3Hz

• Switching Time – 10ms (typical)

On-grid Output

• Rated Output Power – 6000W

• Max. Apparent Power – 12000VA

• Rated Output Current – 26A

• Max. Output Current – 28.6A

• THDi – <3%

• Power Factor – 0.8 leading to 0.8 lagging

• Rated Voltage – 230Vac, single phase

• Frequency – 50Hz / 60Hz

Battery

• Battery Type – Lead-acid / Li-ion / User-defined

• Rated Battery Voltage – 48V (minimum start-up voltage 44V)

• Battery Voltage Range – 40~60Vdc

• Max. PV Charging Current – 100A

• Max. Utility Charging Current – 60A

• Max. Generator Charging Current – 60A

PV Input

• Num. of MPPT – 2

• Max. Input Power – 4500W + 4500W

• Max. Input Current – 16A + 16A

• Max. Short-circuit Current – 27A + 27A

• Max. Open-circuit Voltage – 500Vdc + 500Vdc

• MPPT Operating Voltage Range – 120V ~ 450Vdc

Utility / Generator Input

• Input Voltage Range – 90~280Vac

• Input Frequency Range – 50/60Hz

• Bypass Overload Current – 40A

Efficiency

• MPPT Tracking Efficiency – 99.90%

• Max. Efficiency – 97.50%

General

• Num. of Parallel – 1~6 units

• Dimension – 556345182mm

• Weight – 20kg

• Ingress Protection Degree – IP65
