Key Features

• 12kW rated output power with 24kVA surge
• 48V battery system with wide voltage range (40–60VDC)
• Dual MPPT inputs (6600W + 6600W) with 99.9% tracking efficiency
• Up to 200A combined hybrid charging (PV + grid/generator)
• Pure sine wave output for compatibility with sensitive equipment
• IP65-rated for indoor and outdoor installation
• Supports lithium, lead-acid, and user-defined batteries
• Compatible with BMS via RS485/CAN
• Time-slot function for peak-valley tariff optimization
• WiFi/GPRS monitoring supported
• Parallel-ready: connect up to 6 units

Technical Specifications

Inverter Output

• Rated Output Power – 12000W
• Max. Peak Power – 24000VA
• Rated Output Voltage – 230Vac
• Load Capacity of Motors – 6HP
• Output Frequency – 50/60Hz
• Number of Parallel – 1~6 units

AC Output (Grid)

• Rated Output Power – 12000W
• Max. Apparent Power – 12000VA
• Rated Output Current – 54.5A
• Max. Output Current – 230Vac
• THDI – < 3%
• Power Factor – 0.8 leading to 0.8 lagging
• Frequency – 50/60Hz

Battery

• Battery Type – Lead-acid / Li-ion / User-defined
• Rated Battery Voltage – 48V
• Battery Voltage Range – 40~60Vdc
• Max. Generator Charging Current – 60A
• Max. Grid Charging Current – 120A
• Max. PV Charging Current – 200A
• Max. Hybrid Charging Current – 200A

PV Input

• Num. of MPPT – 2
• Max. PV Array Power – 6600W + 6600W
• Max. Input Current – 22A + 22A
• Max. Voltage of Open-circuit – 500Vdc + 500Vdc
• MPPT Voltage Range – 152~425Vdc

Mains/Generator Input

• Input Voltage Range – 90~280Vac
• Frequency Range – 50/60Hz
• Bypass Overload Current – 63A

Efficiency

• MPPT Tracking Efficiency – 99.90%
• Max. Efficiency – 97.50%
• European Efficiency – 97%

General

• Dimension – 670440240mm
• Weight – 37kg
• Ingress Protection Degree – IP65
• Operating Temperature Range – -25~60°C (>45°C derating)
